Product Specification
|
Item |
Detailed Specification |
|
Inside dimension |
6300×3450×2650 mm (L×W×H) |
|
Outside dimension |
7550×3550×3100mm (L×W×H) |
|
Plenum dimension |
6300×3450×450 mm (L×W×H) |
|
Steel basement |
No steel basement, exhaust from 2 lines pit. |
|
Room body |
Back side 50mm EPS wall panel, the other sides PVC curtain. |
|
Light |
Ceiling Lights: 8Units×4Pcs=32Pcs×36W, with electronic ballasts, lighting boxes are powered coated. |
|
Generator cabinet |
Exhaust from back side, galvanized steel frame; white machine-made panel covered, filled with heat preservation material inside. |
|
Intake and Exhaust system |
1×5.5KW centrifugal motor, air capacity: 18000m3/h, with electric damper. |
|
Purification system |
Pre-filter, ceiling filter, fiberglass filter. |
|
Roof |
Galvanized steel |
|
Control system |
Fan switch, lighting switch, emergency stop. |
|
Installs way |
Hooked from roof by steel cable or supported by steel column. |
|
Total power |
6.7KW (Power supply 1×220V, 3×380V, 50HZ) |
