Description
Description
|
Platform Length |
5600mm |
|
Platform width |
2200mm |
|
Platform height |
520mm |
|
Post Max. tension |
98KN |
|
Pneumatic pressure range |
0.8Mpa |
|
Post working range |
360° full around |
|
Cylinder capacity |
10T |
|
Maximum lift capacity |
3500kgs |
|
Voltage |
3Ph/380v/415v/220v |
|
Weight |
2200kgs |
|
Packing size |
5600*2250*120 mm+2250*1450*570 mm/3.5cbm |
material, improving welding technique and enhancing stress intensity to make the repairing work more precise and faster. One of
important features is no-blind working range, which is in accord with the technician's habit to make more convenient operation. It
can be widely used for nearly all kinds of imported cars, commercial vehicles and SUVs collision repair.
The platform is slot form and reticulation structure which is firstly designed and researched in domestic by ourselves. It
conforms to operating requirement, usage and security of technician at home and abroad. Working platform adopts excellent quality
14# GB I-beam, 6 row I-bean design, very wide(2200mm) and long(5600mm),so it can meet the demand of repairing for small car and
commercial vehicle and other integrated model car., working platform made of rectangular tube steels is designed professionally for body collision repair by choosing better
material, improving welding technique and enhancing stress intensity to make the repairing work more precise and faster. One of
important features is no-blind working range, which is in accord with the technician's habit to make more convenient operation. It
can be widely used for nearly all kinds of imported cars, commercial vehicles and SUVs collision repair.
